Système Biosemi ActiveTwo

Click on the flag to see the version in English:

ENflag1

Version française

Le système d’acquisition Biosemi utilisent des électrodes dites actives qui amplifient le signal au niveau de la tête.

2009n01378h   2009n01379h

Caractéristiques :

  • Casques à 64 électrodes + 8 exogènes (EOG (vEOG, hEOG), Réf)
  • Pose des électrode avec application de gel
  • Logiciel de stimulation : Eprime
  • 2048Hz
  • Convient à des études de recherche
  • Impédances <20 kΩ

Fiche_instrument_EEG_2015-3 (CEP)

electrode eeg  gel

Il est composé d’un pc et d’un logiciel de stimulation et d’un second pc et logiciel d’acquisition.



biosemieeg data

Un schéma précis de branchement des connectiques est disponible dans le box.

cablage_eeg_biosemi

Liens:

EEG_Guidelines, Deirdre BOLGER CREx BLRI

English Version

The Biosemi system is an “active” EEG acquisition system. It is referred to an active system as its electrodes are active, which means that they amplify the signal at the level of the scalp.

2009n01378h 2009n01379h

Characteristics :

  • Head cap with 64 active electrodes + 8 exogenous electrodes (EOG (vEOG, hEOG), References)
  • Applying the head cap requires the application of a conductivity gel.
  • Is synchronised with the Eprime stimulation system.
  • 2048Hz
  • Suitable for research outside of the clinical context.
  • Impedance range: 20 kΩ

Fiche_instrument_EEG_2015-3 (CEP; in French)

electrode eeg gel

The Biosemi acquisition system comprises a computer controlling the presentation of stimuli (Stimulation programme e.g. Eprime) and a computer controlling EEG data acquisition (The Biosemi acquisition programme, Actiview).



biosemieeg data

A connector wiring diagram is available in the box.

cablage_eeg_biosemi

Links:

EEG_Guidelines, Deirdre BOLGER CREx BLRI
